Features:
-2.4 inch TFT display screen, concise user interface and menu hint design.
-Main interface status bar, date/clock indication, fairly obvious alarm host status.
-Built-in powerful performance CPU master based on 32-bit Cortex-M3 core.
-Based on uCOS - III operating system with multitasking design, great user operation experience.
-WIFI/GSM/3G/GPRS intranet alarm system, support different alarm channels, like APP push/SMS/voice monitoring/intranet center etc. to ensure the alarm performance stable and reliable.
-Support SMS arm/disarm and voice arm/disarm.
-Support up to 100 learning/storage location for remote control, RFID cards and wireless detector.
-Support many.
security:
zones, such as gate, SOS, bedroom, window, balcony, perimeter, smoke, gas, carbon monoxide, water leaking, etc.
-Support the main power malfunction, backup power shortage, tamper alarm and other extended alarm.
-Support entry/exit zone, indoor zone, perimeter zone, 24-hour zone..etc.
-Up to 5 groups preset alarm phone numbers, SMS on/off and dial on/off can be set respectively.
-Support external wireless siren.
-Support timing arm and disarm.
-Can store and inquire daily operation records and alarm records.
-GSM network clock synchronization, to ensure accurate clock, and support country time zone setting.
-Support multi-language menu display, voice prompts and alarm SMS setting.
-Can record 20 seconds voice message and alarm voice.
-Telephone function, support 5 groups re-dial number.
-User-friendly APP operation experience and user interface.
-Push Arm/disarm message to APP.
-Support APP remote arm/disarm.
-Online GPRS to obtain equipment status, automatic alarm when offline.
-Reserved remote GPRS TCP / UDP protocol channel, compatible with multiple alarm center networking protocol to facilitate network alarm.
-Center remote control.
Specification:
Input Voltage: DC5V/1A(micro USB jack);
Standby Current: <80uA;
Working Current: <120mA;
Siren output: <500mA;
Wireless Frequency: 315MHZ/433MHZ/868MHZ;
GSM Frequency: 850/900/1800/1900MHZ;
WIFI standard: IEEE802.11b/g/n wireless standard;
Back-up Battery: 3.7V/1000mAh Lithium battery;
Working temperature: -10~55 ℃;
Relative humidity: <80%(No freezing);
Size: 185 x 125 x 14.7mm;
Package included:
1 x Alarm host;
2 x Remote Control;
1 x Wireless Door Sensor;
1 x Wireless Infrared Detector;
2 x RFID cards;
1 x Wired Siren;
1 x USB cable;
1 x Power Adapter;
1 x User Manual
-
